Epoxy Resin Dry Type Transformer

Epoxy Resin Dry Type Transformer is a epoxy resin insulating material made of dry type transformer. It converts voltage, current and impedance through the principle of electromagnetic induction, and utilizes the excellent insulation properties of epoxy resin to ensure stable operation of the transformer under high voltage and high current conditions

Send Inquiry

Product Description

Rated Capacty KVA	Votage Combination(KV)			Connection Symbo	No-load loss (W)	Load Loss (W) (120℃)	Short Circuit Impedance (%) (75℃)	No-load Current (%)	Noise (LPA) (db)	IP00					IP20(IP23)
Rated Capacty KVA	H.V. (KV)	Tapping Range (0/	L.V. (KV)	Connection Symbo	No-load loss (W)	Load Loss (W) (120℃)	Short Circuit Impedance (%) (75℃)	No-load Current (%)	Noise (LPA) (db)	Length (mm)	Width (mm)	Height (mm)	Track Gauge(mm)	weight (kg)	Length (mm)	Width (mm)	Height (mm)	weight (kg)
30	6 6.3 10 30 66	±5 ±2x2.5	0.4	Yyn0 Dyn11	210	745	650		45	850	630	780	400	340	1300	1100	1200	430
50					300	1050	915	4.0	45	880	630	850	400	400	1300	1100	1200	510
80					410	1460	1275		46	1030	630	880	550	570	1500	1200	1200	720
100					450	1665	1455		46	1030	630	1030	550	740	1500	1200	1400	890
125					530	1950	1700		47	1030	630	1050	550	830	1500	1200	1400	980
160					610	2250	1965		48	110	630	1080	550	930	1500	1200	1400	1080
200					700	2670	2330		48	110	630	1140	550	1050	1500	1200	1600	1200
250					810	2920	2550		49	1170	750	1200	660	1200	1700	1300	1600	1370
315					990	3670	3205		49	1170	750	1380	660	1450	1700	1300	1600	1620
400					1100	4220	3685		50	1170	750	1500	660	1650	1700	1300	1800	1820
500					1300	5170	4515		51	1230	750	1500	660	1880	1700	1300	1800	2060
630					1500	6220	5430		52	1350	750	1590	660	2360	1700	1300	1800	2540
630					1460	6310	5510	6.0	52	1400	750	1570	660	2440	1900	1300	1800	2620
800					1710	7360	6425		53	1450	940	1620	820	2700	1900	1500	2000	2900
1000					1990	8600	7510		54	1500	940	1730	820	3100	1900	1500	2000	3300
1250					2350	10260	8955		55	1600	940	1850	820	3700	1900	1500	2000	4000
1600					2750	12420	10840		56	1700	940	1900	1070	4700	2100	1500	2200	5000
2000					3735	15300	13355		56	1800	1240	1950	1070	5400	2100	1800	2200	5700
2500					4500	18180	15870		57	2100	1240	2100	1070	6660	2500	1800	2400	6900

Zi Kai epoxy resin dry type transformer Note

Temperature and altitude: epoxy resin dry transformer should be used within the specified temperature and altitude range. The ambient temperature should not be higher than 40℃, and the altitude should not exceed 1000m.

Ventilation conditions: Whether the air self-cooling (AN) or forced air cooling (AF) cooling method is used, it should be ensured that the transformer installation environment is well ventilated, and the air is clean and dry.

Cleanliness: Keep the transformer installation environment clean to prevent impurities such as dust and dirt from affecting the transformer

epoxy resin dry type transformer application

Power system: as a key equipment for power distribution and transmission, to ensure the stable operation of the grid.

Industrial field: In the manufacturing industry, chemical industry, metallurgy and other industries, to provide stable power support for large equipment.

Commercial buildings: such as shopping centers, office buildings, hotels, etc., used for power distribution and voltage conversion.

Public facilities: such as airports, subways, hospitals, etc., to ensure the reliability and stability of power supply.

Rail transit: In the subway, urban rail and other rail transit system, to ensure the stable operation of power equipment.

New energy field: In wind power, photovoltaic and other new energy power generation systems, as a key equipment for power conversion and grid connection.

Zi Kai epoxy resin dry type transformer Feature

Excellent insulation performance: epoxy resin, as an insulating material, has excellent electrical insulation performance and can withstand the impact of high voltage and high current.

High strength FRP body structure: high and low pressure windings are poured epoxy resin in vacuum and cured to form a high strength FRP body structure, which improves the mechanical strength and stability of the transformer.

Good electrical performance: low partial discharge value, less damage to electrical insulation or local aging phenomenon, to ensure the safe operation of the transformer.

Strong lightning impact resistance: high and low voltage windings are all wound with copper strip (foil), low voltage between layers, large capacitance, foil windings start voltage distribution is close to linear, so its lightning impact resistance is strong.

Strong short-circuit resistance: high and low voltage winding reactance height is the same, no spiral Angle phenomenon, ampere-turns balance between coils, high and low voltage winding due to short circuit caused by the axial force is almost zero, so its strong short-circuit resistance.

Good flame retardant performance: epoxy resin vacuum casting process, no environmental pollution, with maintenance-free, moisture-proof, moisture-heat resistance, flame retardant and self-extinguishing characteristics, suitable for a variety of environments and harsh conditions.

Zi Kai epoxy resin dry type transformer Details

certificates

FAQ

1.What is your packaging standard?

Usually we use standard foam and carton packaging. If you have special requirements, we can also meet your requirements.

2.Why do you buy from us instead of other suppliers?

More than 10 years experience in design and manufacture of high voltage switchgear accessories. It is one of the largest star suppliers in the industry, and has won international and domestic praise, and has been shortlisted for the National Grid.

3.What services can we provide?

Acceptable delivery methods :FOB,CFR,CIF,EXW,FCA, Express;
Accepted payment currency: USD, EUR, GBP, RMB;
Payment methods accepted: Wire transfer, L/C, MoneyGram, credit card, Western Union, cash;
Languages: English, Chinese
